Home > All Collections > High Voltage Rectifier Assemblies > HVAC80-05 Cylindrical High Voltage Rectifier Assembly 80KV 0.5A 50-60Hz

HVAC80-05 Cylindrical High Voltage Rectifier Assembly 80KV 0.5A 50-60Hz

Name: HVAC80-05 Cylindrical High Voltage Rectifier Assembly 80KV 0.5A 50-60Hz
Brand: HVDIODE - Suly Electronics Co., Ltd.
Availability: InStock
Rating: 5 (1 reviews)

Product main features:
1. Nut installation, can also be connected in series.
2. High thermal conductivity epoxy molding compound molding.
3. High voltage end concave structure..
4. High voltage devices that can be connected in series to form higher voltage withstand levels.
5. high temperature resistant chip.
6. Patented products receive a lot of positive reviews.

GET A QUOTE

Desciption

HVAC80-05 Cylindrical High Voltage Rectifier Assembly Data Sheet
Parameter	Symbol	Unit	Test Conditions	Value
Repetitive Peak Backward Voltage	Vrrm	KV	Ta=25℃ Ir=2.0μA	80.0
Peak Working Backward Voltage	Vrwm	KV	Ta=25℃ Ir=2.0μA	80.0
Average Forward Current	If(AV)	A	50Hz Half-sine Wave , Resistance load @Tbreak=50℃	0.5
Backward Recovery Time	Trr	nS		--
Surge Forward Current	Ifsm	A	0.01S @ Half-Sine wave 50Hz	20
Operating Ambient Temperature	Ta	℃		-55～+175
Storage Temperature	Tstg	℃		-55～+150
Forward Peak Voltage	Vfm	V		≥88.0
Backward Peak Current	Irrm1	μA	@ Ta=25℃ VRM=VRRM	2.0
Backward Peak Current	Irrm2	μA	@ Ta=100℃ VRM=VRRM	20.0
Absolute Maximum Ratings & Electrical Characteristics

Unmatched Efficiency in High Voltage Applications
The HVAC80-05 Cylindrical High Voltage Rectifier Assembly is engineered to redefine efficiency in industrial settings. With its robust design, this High Voltage Rectifier ensures optimal performance in demanding environments. The assembly features a nut installation system, allowing for seamless integration into existing setups. Its high thermal conductivity epoxy molding compound enhances heat dissipation, ensuring the High Voltage assembly operates efficiently even under high stress. This HV diode is crafted to withstand high temperatures, thanks to its high-temperature resistant chip, making it a reliable choice for continuous operation. Whether you're dealing with High Voltage Diodes or Surface Mount High Voltage Diode applications, the HVAC80-05 delivers consistent results, ensuring your systems run smoothly and efficiently.

Built for Precision and Performance
Precision and performance are at the core of the HVAC80-05's design. This High Voltage Rectifier is equipped with a high voltage end concave structure, which enhances its ability to handle high voltage levels. The assembly can be connected in series, allowing for higher voltage withstand levels, making it ideal for PCB High Voltage diode and Fast recovery High Voltage diode applications. Its patented design has garnered positive reviews for its reliability and efficiency. The HV diode is designed to handle high currents, making it suitable for High current high voltage diode and High power high voltage diode applications. With the HVAC80-05, you can trust in a product that delivers precision and performance, ensuring your industrial applications are always at their best.

Scalable Design to Meet Growing Demand
As your industrial needs grow, the HVAC80-05 is ready to scale with you. Its design allows for easy integration into larger systems, making it a versatile choice for expanding operations. The Ultra-fast recovery High Voltage diode capabilities ensure that your systems can handle rapid changes in voltage without compromising performance. This High Voltage assembly is built to adapt, providing a future-proof solution for your high voltage needs. Whether you're expanding your current setup or planning for future growth, the HVAC80-05 offers the scalability and reliability you need. With its robust construction and advanced features, this HV diode is the perfect choice for industries looking to stay ahead in a competitive market.

Product Advantages

1. Seamless Integration and Installation
The HVAC80-05 High Voltage Rectifier features a nut installation system, ensuring easy and secure integration into existing setups. This design allows for quick assembly, reducing downtime and enhancing operational efficiency. Its compatibility with Surface Mount High Voltage Diode applications makes it a versatile choice for various industrial environments, ensuring your systems are up and running with minimal hassle.

2. Superior Thermal Management
Engineered with a high thermal conductivity epoxy molding compound, the HVAC80-05 High Voltage assembly excels in heat dissipation. This feature ensures that the HV diode operates efficiently even under high stress, maintaining optimal performance in demanding conditions. The ability to manage heat effectively extends the lifespan of the High Voltage Diodes, providing a reliable solution for continuous operation.

3. Enhanced Voltage Handling
The HVAC80-05 is equipped with a high voltage end concave structure, enhancing its ability to handle high voltage levels. This makes it ideal for PCB High Voltage diode and Fast recovery High Voltage diode applications. The assembly can be connected in series, allowing for higher voltage withstand levels, ensuring your systems can handle increased demands without compromising performance.

4. High-Temperature Resilience
Featuring a high-temperature resistant chip, the HVAC80-05 High Voltage Rectifier is designed to withstand extreme conditions. This resilience ensures consistent performance, making it suitable for High current high voltage diode and High power high voltage diode applications. The robust design guarantees that your industrial applications remain operational, even in the most challenging environments.

5. Scalable and Future-Proof Design
As your industrial needs grow, the HVAC80-05 High Voltage assembly is ready to scale with you. Its design allows for easy integration into larger systems, making it a versatile choice for expanding operations. The Ultra-fast recovery High Voltage diode capabilities ensure that your systems can handle rapid changes in voltage, providing a future-proof solution that adapts to your evolving requirements.

Usage Scenarios

Scenario 1: Industrial Power Supply Optimization
In a manufacturing plant, maintaining consistent power supply is crucial. The HVAC80-05 High Voltage Rectifier ensures stable power conversion, reducing downtime. Its high thermal conductivity and nut installation allow seamless integration into existing systems. This High Voltage assembly is ideal for handling high currents, making it a perfect fit for High current high voltage diode applications, ensuring efficiency and reliability.

Scenario 2: Renewable Energy Systems
For solar farms, efficient energy conversion is key. The HVAC80-05 excels in PCB High Voltage diode setups, thanks to its high-temperature resistant chip. Its ability to connect in series enhances voltage withstand levels, crucial for High power high voltage diode applications. This HV diode ensures that energy systems operate smoothly, maximizing output and reducing energy loss.

Scenario 3: Medical Imaging Equipment
In medical imaging, precision is paramount. The HVAC80-05 supports Fast recovery High Voltage diode applications, ensuring quick response times in imaging devices. Its robust design and high voltage end concave structure make it reliable under high stress, providing consistent performance in critical healthcare environments.

Scenario 4: Telecommunications Infrastructure
Telecom towers require reliable components to handle fluctuating voltages. The HVAC80-05 offers Ultra-fast recovery High Voltage diode capabilities, adapting to rapid voltage changes without performance loss. Its scalable design allows for easy integration into expanding networks, ensuring uninterrupted communication services.

Scenario 5: Aerospace Systems
In aerospace, components must withstand extreme conditions. The HVAC80-05 High Voltage Rectifier is built for such environments, withstanding high temperatures and ensuring durability. Its application in Surface Mount High Voltage Diode systems enhances performance, making it a trusted choice for aerospace technology, ensuring safety and reliability.

About Us

HVDIODE is a leading provider of high-performance high voltage rectifier assemblies, dedicated to delivering unmatched efficiency and reliability in industrial applications. Our HVAC80-05 Cylindrical High Voltage Rectifier Assembly is designed to redefine efficiency in demanding environments, featuring a robust design that ensures optimal performance. With a nut installation system for seamless integration and high thermal conductivity epoxy molding compound for enhanced heat dissipation, our products operate efficiently even under high stress. Our high-temperature resistant chip makes the HVAC80-05 a reliable choice for continuous operation, ensuring your systems run smoothly and efficiently. At HVDIODE, precision and performance are at the core of our design philosophy. Our high voltage end concave structure enhances the ability to handle high voltage levels, making our products ideal for PCB High Voltage diode and Fast recovery High Voltage diode applications. With a patented design that has garnered positive reviews for reliability and efficiency, our HV diode is suitable for high current and high power applications. As your industrial needs grow, HVDIODE is ready to scale with you, offering easy integration into larger systems and ultra-fast recovery capabilities to handle rapid changes in voltage without compromising performance. Our commitment to scalability and reliability ensures that industries can stay ahead in a competitive market. Choose HVDIODE for a future-proof solution to your high voltage needs.

Contact HVDIODE today to upgrade your industrial operations with the HVAC80-05 Cylindrical High Voltage Rectifier Assembly. Let’s enhance efficiency and reliability!

FAQ

Q1: Who are we?
We are HVDIODE, a leading provider of high-performance high voltage rectifier assemblies designed for industrial applications. Our products are engineered to deliver unmatched efficiency and reliability in demanding environments.

Q2: How can we guarantee quality?
We ensure quality through rigorous testing and the use of high-grade materials, such as high thermal conductivity epoxy molding compounds and high-temperature resistant chips. Our patented designs are crafted to meet the highest industry standards, ensuring durability and consistent performance.

Q3: What can you buy from us?
You can purchase a wide range of high voltage diodes and rectifier assemblies, including the HVAC80-05 Cylindrical High Voltage Rectifier Assembly. Our products cater to various applications, from surface mount high voltage diodes to ultra-fast recovery high voltage diodes.

Q4: Why should you buy from us not from other suppliers?
Our products are designed with precision and performance in mind, featuring innovative designs like the high voltage end concave structure for enhanced voltage handling. We offer scalable solutions that adapt to your growing industrial needs, ensuring your systems remain efficient and reliable.

Q5: What services can we provide?
We provide comprehensive support, including product customization and technical assistance, to ensure seamless integration into your existing systems. Our team is dedicated to helping you achieve optimal performance with our high voltage solutions.

Q6: Can I customize this product for my business?
Yes, the HVAC80-05 can be customized to meet specific industrial requirements. Our team works closely with you to tailor the product to your unique needs, ensuring seamless integration and optimal performance.

Q7: How fast can I receive my order?
We strive to process and ship orders promptly to meet your operational timelines. Delivery times may vary based on location and order specifications, but we are committed to ensuring you receive your products as quickly as possible.
